Hinged insulated system BM-11000
Description
BM-11000 is a Tilt & Turn insulated hinged system that can meet the most demanding needs thanks to a large variety of solutions and designs
Advantages
- High value for money
- High energy savings due to the high energy efficiency of the system
- Special solutions for Hotels
- Wide variety of solutions
- Increased level of security
- High level of sound insulation
- Ease of use and high functionality
- Modern design for windows either with flat or curved line
- Enhanced natural light thanks to the ability to use hidden sash
- High quality with certified performance
- Increased static loads and functionality in case of severe weather conditions
Generic
WINDOWS TYPES | THERMAL INSULATION | EXTERIOR SHAPES |
---|---|---|
Hinged | Yes | Classic, Curved, Flat |
Technical Characteristics
FRAME DEPTH | SASH DEPTH | SASH WEIGHT | MINIMUM VISIBLE ALUMINIUM FACE HEIGHT | MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (ADJOINING PROFILE) | GLAZING TYPE | MAXIMUM GLAZING THICKNESS | MECHANISM | SEALING METHOD | TYPE OF THERMAL INSULATION |
---|---|---|---|---|---|---|---|---|---|
62,5 mm | 70 mm | up to 180 Kg | 70 mm | 61 mm | Single – Double – Triple | from 20 up to 59 mm | Euro-groove, Euro-nut | Perimetrical at 3 levels with EPDM gaskets | Polyamides 24 mm & 20 mm |
Performance
UF | WATER TIGHTNESS | AIR PERMEABILITY | SOUND REDUCTION |
---|---|---|---|
from 2,3 up to 2,9 W/m²K | CLASS Ε900 | CLASS 4 | 47 dB |
Characteristics
TYPES OF TYPOLOGY |
---|
For all tilt & turn typologies |
TYPOLOGIES
![typologies-bm11000-01](https://www.baufit.ba/wp-content/uploads/2022/05/typologies-bm11000-01.png)
One sash tilt and turn
![typologies-bm11000-02](https://www.baufit.ba/wp-content/uploads/2022/05/typologies-bm11000-02.png)
Τilt and turn with fix light on top
![typologies-bm11000-03](https://www.baufit.ba/wp-content/uploads/2022/05/typologies-bm11000-03.png)
Τilt and turn with fanlight
![typologies-bm11000-04](https://www.baufit.ba/wp-content/uploads/2022/05/typologies-bm11000-04.png)
Double tilt and turn window
![typologies-bm11000-05](https://www.baufit.ba/wp-content/uploads/2022/05/typologies-bm11000-05.png)
Double tilt and turn with light
![typologies-bm11000-06](https://www.baufit.ba/wp-content/uploads/2022/05/typologies-bm11000-06.png)
Horizontal pivot window
![typologies-bm11000-07](https://www.baufit.ba/wp-content/uploads/2022/05/typologies-bm11000-07.png)
Vertical pivot window
![typologies-bm11000-08](https://www.baufit.ba/wp-content/uploads/2022/05/typologies-bm11000-08.png)
Double tilt and turn window with fixed light
![typologies-bm11000-09](https://www.baufit.ba/wp-content/uploads/2022/05/typologies-bm11000-09.png)
Double tilt and turn with fanlight
![typologies-bm11000-010](https://www.baufit.ba/wp-content/uploads/2022/05/typologies-bm11000-010.png)
Double tilt and turn with fixed lights sideways
![typologies-bm11000-11](https://www.baufit.ba/wp-content/uploads/2022/05/typologies-bm11000-11.png)
Single tilt & turn casement (Concealed sash)
![typologies-bm11000-12](https://www.baufit.ba/wp-content/uploads/2022/05/typologies-bm11000-12.png)
Single tilt & turn casement with fixed light (Concealed sash)
![typologies-bm11000-08](https://www.baufit.ba/wp-content/uploads/2022/05/typologies-bm11000-08.png)
Single tilt & turn casement with fixed light (Concealed sash)
![typologies-bm11000-13](https://www.baufit.ba/wp-content/uploads/2022/05/typologies-bm11000-13.png)
Hinged door inwards/outwards
![typologies-bm11000-14](https://www.baufit.ba/wp-content/uploads/2022/05/typologies-bm11000-14.png)
Double leaf door inwards/outwards opening
![typologies-bm11000-15](https://www.baufit.ba/wp-content/uploads/2022/05/typologies-bm11000-15.png)
Hinged door inwards/outwards with insulation panel & fixed pane
![typologies-bm11000-16](https://www.baufit.ba/wp-content/uploads/2022/05/typologies-bm11000-16.png)
Hinged door inwards/outwards with insulation panel, fixed pane & fanlight
